उत्पाद का विवरण
Place of Origin: China
ब्रांड नाम: Brictec
प्रमाणन: CE ISO
Model Number: DQP765*2100
भुगतान और शिपिंग की शर्तें
Minimum Order Quantity: 1 set
मूल्य: USD 82,400/ set
Packaging Details: Customized
Delivery Time: 80 days
Payment Terms: T/T, L/C
Supply Ability: Customized
Automatic: |
Yes |
Condition: |
New |
Material: |
Steel |
Cutting frequency: |
15–45 times/min |
Max cutting width: |
1200 mm |
Color: |
Accordinng your need |
Power Source: |
Electric |
After-sales service provided: |
Engineers available to service machinery overseas |
Voltage: |
380V,220V,220/240/380/440V,it depends on exact conditions,Adjustable |
Warranty: |
1 Year |
Raw material: |
Clay Soil Earth Fly ash and so on |
Automatic: |
Yes |
Condition: |
New |
Material: |
Steel |
Cutting frequency: |
15–45 times/min |
Max cutting width: |
1200 mm |
Color: |
Accordinng your need |
Power Source: |
Electric |
After-sales service provided: |
Engineers available to service machinery overseas |
Voltage: |
380V,220V,220/240/380/440V,it depends on exact conditions,Adjustable |
Warranty: |
1 Year |
Raw material: |
Clay Soil Earth Fly ash and so on |
1 Equipment Introduction
The chamfered wire-cutting machine is a hybrid unit that integrates a chamfering knife holder into a conventional wire cutter, performing both length-cutting and 45°/30° chamfering in one stroke for wet green bricks of clay, shale or coal gangue fired bricks.
2 Cutting Features
• Chamfering and cutting are completed in one pass without secondary handling;
• Adjustable chamfer angle from 45° to 90°;
• Individual wire quick-change on breakage, no shutdown;
• PLC servo synchronization, cutting accuracy ≤ ±1 mm.
3 Cutting Advantages
• One-step chamfering improves stacking and laying efficiency;
• Reduces corner chipping by ≥80 %;
• Modular blade holder, 10 min change-over;
• Eliminates manual edge trimming, overall cost reduced by ~15 %.
4 Machine Construction
• High-rigidity twin-screw frame ensures cutting stability;
• Swiveling chamfer knife seat with electric angle adjustment;
• Snap-in wire assembly for easy maintenance;
• Stainless steel water-cooling trough suppresses dust and prolongs wire life.
5 Specifications
| Item | Value |
| Max cutting width | 1,200 mm |
| Cutting frequency | 15-45 cuts/min (frequency conversion) |
| Chamfer angle | 30°-90° (Adjustable) |
| Installed power | 11 kW |
| Applicable bricks | Solid Bricks, Perforated Bricks, Hollow Bricks |
6 Benefits of Chamfered Bricks
• Rounded edges make handling and construction safer;
• Mortar joints are fuller and neater, reducing subsequent plastering;
• Enhances overall wall strength by lowering corner stress concentration;
• Meets modern architectural demands for fair-faced or decorative walls.
